High Buoyancy Marine Navigation Buoys

High Buoyancy Marine Navigation Buoys
High Buoyancy Marine Navigation Buoys High Buoyancy Marine Navigation Buoys

Large Image :  High Buoyancy Marine Navigation Buoys

Product Details:
Place of Origin: Shandong, China
Brand Name: Jerryborg
Certification: BV, Lr, Dnvgl, ABS, CCS
Payment & Shipping Terms:
Minimum Order Quantity: negotiable
Price: negotiable
Packaging Details: nude packing
Delivery Time: 10-20 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000 pieces per year

High Buoyancy Marine Navigation Buoys

Description
Material: PE Color: Orange, Red, Black, Grey
Certificate: BV, Lr, Dnvgl, ABS, CCS Product Name: Mooring Buoy
Diameter: Customized Size: Customized
Warranty: 24 Months
High Light:

2.5m Marine Navigation Buoys

,

BV Marine Navigation Buoys

,

1.0m Boat Mooring Buoy

Floating Mooring Marker Buoy Marine Navigation Buoys With High Buoyancy





How To Use Floating Mooring Marker Buoy Correctly



It’s important to use a floating mooring marker buoy correctly to prevent unnecessary wear and tear on the mooring system, as well as protect your vessel and the vessels of others. There is no fee to use the reef floating mooring marker buoys maintained by the sanctuary, but there are floating mooring marker buoys in anchorages throughout the Keys that do charge a fee.

  • Buoys are available on a first-come, first-served basis.
  • Steer the boat from a helm station that enables you to see the buoy during the entire hook up.
  • Approach slowly from downwind or down current, so that the floating yellow pick-up line is closest to you. Keep the buoy on the same side as the helm station so you can see it as you approach.
  • Safely retrieve the yellow pick-up line with a boat hook. Put your vessel in neutral to avoid entanglement.
  • Run your boat’s bow line through the loop of the yellow pick-up line. Cleat both ends of your bow line to the bow of your boat. Never tie the yellow pick-up line directly to your boat as it puts undue stress on the mooring anchor. Never stern tie to a buoy either as this is both dangerous to you and your boat, but also puts undue strain on the mooring system.
  • Let out enough line so that the buoy is not pulled underwater and the line is horizontal. Rougher days may require even more lines. Adding an extra line will produce a more comfortable experience for your vessel while moored and reduce wear on the buoy system.
  • Inspect the buoy your boat is tied to; you are responsible for your vessel. Check that it is holding as intended and report problems to any of the sanctuary offices.
  • When you are ready to leave, un-cleat your boat’s bow line and pull it through the loop of the yellow pick-up line. Then back well away from the mooring so you do not foul in any of the mooring lines.



Additional Attention Points of Floating Mooring Marker Buoy



  • At many reefs, floating mooring marker buoys encircle the shallowest reef areas or are located on the ocean side of the reef. Approach floating mooring marker buoys from around either side of these shallow areas, always steering to the outside of a ring of buoys. Never motor directly across a shallow reef to get to a buoy.
  • You should maintain idle speed/no wake in the vicinity of the floating mooring marker buoys. Do not meander among the buoys and watch for swimmers, snorkelers, and diver bubbles.
  • If there are no buoys available, anchor only in sand, never in coral. Always check to be sure that your anchor is not dragging and your anchor chain is not contacting coral.
  • Smaller boats are encouraged to tie off to one another, thereby allowing larger vessels access to buoys.
  • Sailboats should not leave up large sails as steadying sails when on a buoy; this puts too much strain on the mooring’s eyebolt.
  • Buoy locations have been spaced to provide clearance for most boats when tied up during normal conditions. To avoid grounding, use caution when approaching and while tied to a buoy. Larger-than-average vessels must check depths so that contact with the bottom is avoided.
  • Florida Keys National Marine Sanctuary assumes no liability for use of the buoys.

marine navigation buoy



Advantage of Floating Mooring Marker Buoy



  • Tough, impact-resistant polyethylene plastic (HDPE/MDPE/LLDPE)
  • Built-in UV inhibitors reduce degradation caused by sunlight
  • Handholds to ease Pipe Float installation
  • Molded-in bolt holes allow for easy float installation
  • Floats are available with or without foam cores
  • Solid one-piece construction



Specification of Floating Mooring Marker Buoy



Diameter(m)
Length(m)
Energy Absorption(KJ)
Reactive Force(KN)
1.0
1.5
40
226
1.0
2.0
56
321
1.2
2.0
79
371
1.5
3.0
191
724
1.7
3.0
238
796
2.0
3.5
385
1094
2.5
4.0
829
1725
2.5
5.5
1165
2513
3.0
5.0
1313
2538
3.0
6.0
1644
3110
3.3
6.5
2130
3647



For further information free to contact us.
