Cylindrical Inflatable Boat Marine Rubber Airbags

Cylindrical Inflatable Boat Marine Rubber Airbags
Cylindrical Inflatable Boat Marine Rubber Airbags Cylindrical Inflatable Boat Marine Rubber Airbags Cylindrical Inflatable Boat Marine Rubber Airbags Cylindrical Inflatable Boat Marine Rubber Airbags

Large Image :  Cylindrical Inflatable Boat Marine Rubber Airbags

Product Details:
Place of Origin: Shandong, China
Brand Name: Jerryborg
Certification: ISO17357 CCS BV
Model Number: 1.2m*15m
Payment & Shipping Terms:
Minimum Order Quantity: negotiable
Price: negotiable
Packaging Details: nude packing
Delivery Time: 10-20 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000 pieces per year

Cylindrical Inflatable Boat Marine Rubber Airbags

Description
Brand Name: Jerryborg Material: NR
Size: Customized Size Accessories: Inflatable Tool, Pull Ring
Shape: Cylindrical Body Certificate: CCS,BV,LR,ABS,
Port: Qingdao Port Warranty: 24 Months
High Light:

Boat Marine Rubber Airbags

,

Inflatable Marine Rubber Airbags

,

Cylindrical Marine Rubber Airbags

Marine Ship Launching Airbags Inflatable Boat Rubber Airbags





Ship Launching Airbags Description



Ship launching airbags are also called roller bags, ship launching rubber balloons, which are designed to be a cylindrical shape. They are made of inner reinforced synthetic-tire-cord layers and outer rubber layers that are strong to withstand compression and twisting.



Ship launching airbags are accepted by more and more shipyards worldwide due to its’ advantage of saving labor cost and time, besides it’s easy to install and replace. Ship launching airbags are widely used in ship launching, ship salvage, and other heavy weights lifting and moving. Jerryborg supplies various sizes of ship launching airbags depending on the customer’s request.





Ship Launching Airbags Features



  • cost-effective
  • portable and easy installation
  • high capacity against compression and twisting
  • big carrying capacity
  • anti-aging resistance with a lifespan
  • new design of anti-explosion construction
  • beyond space limitation





Ship Launching Airbags Application



Ship launching airbags, called marine rubber airbags are also widely used in other applications.

  • Ship launching & upgrading
  • Ship salvage operations
  • Heavy weights moving & lifting
  • Caissons lifting & floating
  • Pipeline blocking

ship launching airbags





Ship Launching Airbags Structure



Ship launching airbags are composed of the outer rubber layer, inner rubber layer, and synthetic tire cord layer. The cord layers consist of 4-10 layers which are strong enough to withstand the external forces. the ship launching airbag is designed to be a cylindrical body with two heads. Jerryborg also supplies the accessories like pull ring, pressure gauge, three-way piece, ball valve, and connecting pipe.

ship launching airbag





Ship Launching Airbags Specification



Series Model Diameter(m) Working Pressure(Mpa) Working Height(m) Beating Capacity(Ton/m)
0.4D 0.5D 0.6D 0.4D 0.5D 0.6D
S1



S10

0.8 0.20 0.32 0.40 0.48 15.1 12.6 10.0
1 0.16 0.40 0.50 0.60 15.1 12.6 10.0
1.2 0.14 0.48 0.60 0.72 15.8 13.2 10.6
1.5 0.11 0.60 0.75 0.90 15.5 13.0 10.4
S11 0.8 0.19 0.32 0.40 0.48 14.3 11.9 9.5
1 0.15 0.40 0.50 0.60 14.1 11.8 9.4
1.2 0.13 0.48 0.60 0.72 14.7 12.2 9.8
1.5 0.10 0.60 0.75 0.90 14.1 11.8 9.4
S12 0.8 0.24 0.32 0.40 0.48 18.1 15.1 12.1
1 0.19 0.40 0.50 0.60 17.9 14.9 11.9
1.2 0.16 0.48 0.60 0.72 18.1 15.1 12.1
1.5 0.13 0.60 0.75 0.90 18.4 15.3 12.2
1.8 0.10 0.72 0.90 1.08 17.0 14.1 11.3
S2 S20 1 0.24 0.40 0.50 0.60 22.6 18.8 15.1
1.2 0.20 0.48 0.60 0.72 22.6 18.8 15.1
1.5 0.16 0.60 0.75 0.90 22.6 18.8 15.1
1.8 0.13 0.72 0.90 1.08 22.0 18.4 14.7
2 0.12 0.80 1.00 1.20 22.6 18.8 15.1
S21 1 0.27 0.40 0.50 0.60 25.4 21.2 17.0
1.2 0.23 0.48 0.60 0.72 26.0 21.7 17.3
1.5 0.18 0.60 0.75 0.90 25.4 21.2 17.0
1.8 0.15 0.72 0.90 1.08 25.4 21.2 17.0
2 0.14 0.80 1.00 1.20 26.4 22.0 17.6
S22 1 0.31 0.40 0.50 0.60 29.2 24.3 19.5
1.2 0.26 0.48 0.60 0.72 29.4 24..5 19.6
1.5 0.20 0.60 0.75 0.90 28.3 23.6 18.8
1.8 0.17 0.72 0.90 1.08 28.8 24.0 19.2
2 0.15 0.80 1.00 1.20 28.3 23.6 18.8
2.5 0.12 1.00 1.25 1.50 28.3 23.6 18.8
S3 S30 1 0.35 0.40 0.50 0.60 33.0 27.5 22.0
1.2 0.29 0.48 0.60 0.72 32.8 27.3 21.9
1.5 0.23 0.60 0.75 0.90 32.5 27.1 21.7
1.8 0.19 0.72 0.90 1.08 32.2 26.8 21.5
2 0.17 0.80 1.00 1.20 32.0 26.7 21.4
2.5 0.14 1.00 1.25 1.50 33.0 27.5 22.0

For further information free to contact us.
